Features
Output sine wave
Maximum efficiency 90%
Intelligent speed regulation of fan: if the load is greater than 600W or the temperature inside the fan is greater than 50 ℃, the fan speed will be controlled according to the load and the temperature inside the fan
Protection function: input under voltage protection, input over voltage protection, overload protection, short circuit protection, over temperature protection
Application: home, office, vehicle, yacht and other occasions
Product Data Sheet
Model | SAK-0312E/ SAK-0312 | SAK-0612E/ SAK-0612 | SAK-1212E/ SAK-1212 | SAK-2012E/ SAK-2012 | |
Input | Rated Input Voltage | 12V | 12V | 12V | 12V |
Rated Current | 30A | 56A | 112A | 210A | |
Maximum Efficiency | 90% | 90% | 90% | 90% | |
Battery Type | lead acid / lithium battery | ||||
AC Output | Rated Power | 300W | 600W | 1200W | 2000W |
AC Voltage | 220V/110V | 220V/110V | 220V/110V | 220V/110V | |
Frequency | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ | |
Wave form | sine wave | sine wave | sine wave | sine wave | |
Input Protection | Battery Low Voltage Alarm | 10.5V | 10.5V | 10.5V | 10.5V |
Battery Low Voltage Recovery | 11.0V | 11.0V | 11.0V | 11.0V | |
Battery Low Voltage Shutdown | 10.0V | 10.0V | 10.0V | 10.0V | |
Output Protection | Output Short Circuit Protection | After the fault is eliminated, it can be rebooted | |||
Overload Protection | 110%≤load＜125%，1 minute shutdown； 125%≤load＜150%，30s shutdown； 150%≤load，Shut down immediately. | ||||
Over Temperature Protection | |||||
Operating Environment | Operating Temperature | 0-40℃ | |||
Humidity | 0-80% | ||||
Other | Dimension | 305*172.5*75.25mm | |||
Remote Control Switch Interface | Standard configuration | ||||
USB | 5V2A | ||||
