Features:
Pure sine wave solar inverter
Built-in 40A MPPT solar charger
PV input voltage range 20-150VDC(for 1000W),30-150VDC(for 1500W)
Built-in anti-dust kit for harsh environment
Smart battery charge design to optimize battery life
meet rich customized demands
Solar energy is provided directly to the load first
| MODEL | NMS-1000W | NMS-1500W |
| Rated Output Power | 1000VA/1000W | 1500VA/1500W |
| AC INPUT | ||
| Voltage | 230VAC | |
| Selectable Voltage Range | 170-280VAC(For Personal Appliances) | |
| 90-280VAC (For Home Appliances) | ||
| Frequency Range | 50Hz/60Hz(Auto sensing) | |
| AC OUTPUT | ||
| AC Voltage Regulation | 230VAC±5% | |
| Surge Power | 2000VA | 3000VA |
| Efficiency(Peak)PV to INV | 98% | |
| Efficiency(Peak)Battery to INV | 94% | |
| Transfer Time | 10ms | |
| BATTERY | ||
| Battery Voltage | 12VDC | 24VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC |
| Overcharge Protection | 16VDC | 32VDC |
| SOLAR CHARGER & AC CHARGER | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Power | 600W | 1200W |
| MPPT Range @ Operating Voltage | 20-150VDC | 30-150VDC |
| Maximum PV Array Open Circuit Voltage solar | 150VDC | |
| Maximum Solar Charge Current | 40A | |
| Maximum AC Charge Current | 40A | |
| Maximum Charging Current(Solar+AC) | 80A | |
| PHYSICAL | ||
| Dimension,D*W*H(mm) | 290*240*91 | |
| Carton Dimension,D*W*H(mm) | 340*290*145 | |
| Net Weight(kgs) | 3 | 3.5 |
| Gross Weight(kgs) | 3.5 | 4 |
| ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Operationg Temperature | -10℃-50℃ | |
| STANDARD | ||
| Compliance Safety | CE | |
