Features
Pure sine wave output
Output power factor 1.0
Programmable supply priority for PV，Battery or Grid
User-adjustable charge current and voltage
Wide PV input range (120Vdc -500Vdc)，110A MPPT SCC
Working without batteries in sunny day
WIFI Monitoring Function (optional)
Anti-dusk kit for harsh environment(optional)
LCD remote control with 10 meters wire(optional)
PV and electricity complementary
Use with lithium batteries
Remove LCD
Product Data Sheet
MODEL | HGS PRO 3500W | HGS PRO 5500W |
Rated Power | 3500VA/3500W | 5500VA/5500W |
INPUT | ||
Voltage | 230VAC | |
Selectable Voltage Range | 170-280VAC（for personal computers） 90-280VAC（for home appliances） | |
Frequency Range | 50Hz/60Hz（Auto sensing） | |
OUTPUT | ||
AC Voltage Regulation（Batt . Mode） | 230VAC±5% | |
Surge Power | 7000VA | 11000VA |
Efficiency（Peak）PV to INV | 97% | |
Efficiency（Peak）BAT to INV | 94% | |
Transfer Time | 10ms（for personal computers） 20ms（for home appliances） | |
Wave form | Pure Sine Wave | |
BATTERY&AC CHARGER | ||
Battery Voltage | 24VDC | 48VDC |
Floating Charge Voltage | 27VDC | 54VDC |
Overcharge Protection | 33VDC | 63VDC |
Maximum charge current | 80A | 80A |
SOLAR CHARGER | ||
MAX.PV Array Power | 5000W | 6000W |
MPPT Range@ Operating Voltage | 120-450VDC | |
Maximum PV Array Open Circuit Voltage | 500VDC | |
Maximum Charging Current | 110A | |
Maximum Efficiency | 98% | |
PHYSICAL | ||
Dimension. D*W*H（mm） | 472*298*143 | |
Net Weight（kgs） | 9.5kg | 10.5kg |
Communication Interface | RS485/RS232（Standard） WIFI（Optional） | |
OPERATING ENVIRONMENT | ||
Humidity | 5% to 95% Relative Humidity（Non-condensing） | |
Operating Temperature | 0℃ to 55℃ | |
Storage Temperature | -15℃ to 60℃ | |
