Features
Pure sine wave solar inverter(on/off Grid)
Output power factor 1.0
WIFI&GPRS available for lOS and Android
Inverter can run without battery
One-key restoration to factory Settings
Built-in Lithium battery automatic activation
Built-in 120A MPPT Solar charge:max 6200W(for 3.6KW)max 6500W (for 6.2KW)
High PV input voltage range(60~500VDC)
Built-in anti-dust kit for harsh environment
Smart battery charge design to optimize battery life
Dual output
Built Remove LCD Display and Key
| ODEL | ECO PRO-3.6KW | ECO PRO-4.2KW | ECO PRO-6.2KW |
| Phase | 1-Phase | ||
| Maximum PV Input Power | 6200W | 6200W | 6500W |
| Rated Output Power | 3600W | 4200W | 6200W |
| Maximum Solar Charging Current | 120A | ||
| GRID-TIE OPERATION | |||
| PV Input(DC) | |||
| Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | ||
| Start-Up Voltage/Initial Feeding Voltage | 60VDC/90VDC | ||
| MPPT Voltage Range | 60~450VDC | ||
| Number of MPPT Trackers/Maximum Input Current | 1/18A | 1/22A | |
| GRID OUTPUT(AC) | |||
| Nominal Output Voltage | 220/230/240VAC | ||
| Output Voltage Range | 195.5-253VAC | ||
| Nominal Output Current | 15.7A | 18.2A | 27.0A |
| Power Factor | >0.99 | ||
| Feed-in Grid Frequency Range | 49-51+1Hz | ||
| EFFICIENCY | |||
| Maximum Conversion Efficiency(Solar to AC) | 98% | ||
| TWO LOAD OUTPUT POWER(v2.0) | |||
| Full Load | 3600W | 4200W | 6200W |
| Maximum Main Load | 3600W | 4200W | 6200W |
| Maximum Second Load(battery mode) | 1200W | 1400W | 2067W |
| Main Load Cut Off Voltage | 22VDC | 22VDC | 44VDC |
| Main Load Return Voltage | 26VDC | 26VDC | 52VDC |
| OFF-GRID OPERATION | |||
| AC Input | |||
| AC Start-up Voltage/Auto Restart Voltage | 120-140VAC/180VAC | ||
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | ||
| Maximum AC Input Current | 30A | 40A | |
| Nominal operating frequency | 50/60HZ | ||
| Surge power | 7200W | 8400W | 10000W |
| BATTERY MODE OUTPUT(AC) | |||
| Nominal Output Voltage | 220/230/240VAC | ||
| Output Waveform | Pure sine wave | ||
| Efficiency(DC to AC) | 94% | ||
| BATTERY&CHARGER | |||
| Nominal DC Voltage | 24VDC | 24VDC | 48VDC |
| Maximum Charging Current(Solar to AC) | 120A | ||
| Maximum AC Charging Current | 100A | ||
| GENERAL | |||
| PHYSICAL | |||
| Dimension,D*W*H（mm） | 420*350*110 | ||
| Cartoon Dimension, D*W*H（mm） | 500*415*215 | ||
| Net Weight(kgs) | 9 | 9.5 | 10 |
| Gross Weight(kgs) | 10 | 9.5 | 11 |
| INTERFACE | |||
| Communication Port | RS232WIFIGPRS/LITHIUM BATTERY | ||
